Gewiss GW66015 Industrial Socket 32A 2P+E IP44 — Interlocked Horizontal

The Gewiss GW66015 Interlocked Horizontal Socket Outlet is a heavy‑duty 32A, 230V connector built for demanding industrial and commercial environments. It features an interlocked mechanism for safe operation and an IP44 rating for splash protection.

Key Features

• 32A, 2P+E, 230V AC (50/60 Hz)
• IP44 splash-proof and dust resistant housing
• Interlocked mechanism: connect/disconnect only when the switch is OFF
• Horizontal mounting with bottom entry
• Blue housing with 230V indication
• IEC 60309 compliant; 6H hour position for reliable mating
• Robust technopolymer housing with high mechanical strength
• Dimensions: ~225 × 170 × 140 mm | Weight: ≈ 1.15 kg
• EAN/GTIN: 8011564017995

Technical Specifications

Applications

• Industrial facilities and workshops
• Construction sites and logistics hubs
• Food processing and commercial kitchens
• Outdoor or semi-outdoor electrical distribution requiring splash protection

FAQ

• What does "interlocked" mean on this socket?
  An interlocked socket has a mechanical or electrical lock that only allows the plug to be inserted or removed when the socket's isolating switch is in the OFF position — preventing anyone from plugging or unplugging equipment while it's live. This is typically required by site safety rules for higher-current industrial connections.
• What does 2P+E mean?
  It's a 3-pin configuration: line, neutral, and earth — the standard arrangement for single-phase 230V industrial power connections.
• What does the IP44 rating mean, and is this suitable outdoors?
  IP44 means it's protected against solid objects larger than 1mm and splashing water from any direction — suitable for outdoor use and damp site conditions, but not for full immersion or direct jetting/hosing down. Check the enclosure is fitted correctly (cover closed, gland sealed) to maintain the rating in practice.
• How is this socket mounted?
  Check the product title/Technical Specifications for the exact mounting style — flush-mount sockets are recessed into a panel or wall, surface-mount sockets are fixed to the wall/enclosure face, and interlocked sockets are typically panel-mounted with an integral isolating switch.
• Can I install this myself?
  No. This is a fixed socket outlet wired into a permanent electrical installation or distribution board, and should be installed and connected by a licensed electrician in accordance with UAE wiring regulations.
