ABB KSE340TPN Switch Disconnector 40A 3 Pole IP65

ABB KSE340TPN Enclosed Switch Disconnector

The KSE340TPN is a 3-pole enclosed switch disconnector rated at 25A, housed in a rugged aluminium enclosure with IP65 protection. Built for both indoor and outdoor use, it offers reliable local isolation for machinery, feeders, and distribution circuits, with UV-protected paintwork and weatherproof sealing well suited to the dust and heat conditions typical of UAE outdoor installations.

Key Features

• 3-pole switch disconnector rated 25A (AC-23A) with fixed neutral and PE terminal for 5-wire system installations
• IP65-rated aluminium enclosure, protected against low-pressure water jets, suitable for outdoor and indoor mounting
• Padlockable, side-operated handle with interlocked cover for safe isolation during maintenance
• Threaded cable entries for 2 parallel cables from top and bottom, with membrane grommets included for IP54 sealing
• Genuine ABB quality — impact-resistant housing rated IK09

Technical Specifications

Applications

• Local isolation for HVAC units, pumps, and outdoor machinery in commercial and industrial sites
• Main isolation switch for external distribution boards exposed to UAE outdoor conditions
• Safe isolation point for maintenance on rooftop and plant room equipment
• Feeder isolation in FM-managed facilities requiring IP65-rated enclosures

FAQ

• Is this an MCB or an isolator?
  It's an isolator (switch-disconnector), not an MCB. It has no overload or short-circuit protection — it only provides a manual on/off disconnect, and should be paired with separate MCBs or RCCBs for circuit protection.
• What does 3-pole mean for this isolator?
  3-pole means it switches all three phases on a three-phase supply.
• Where should this isolator be installed?
  Typically as the main incoming switch or a local isolation point ahead of the MCBs/RCCBs in a distribution board, so the whole board (or a section of it) can be isolated for maintenance without needing to trip individual breakers.
• Can I install this myself?
  No. This is trade-only distribution board equipment and must be installed and connected by a licensed electrician in accordance with local wiring regulations.
• Can this isolator be used to switch a live circuit under load?
  Isolators rated for on-load switching can do this within their utilisation category, but check the specific AC rating in the Technical Specifications table — an isolator is not a protective device and should not substitute for a circuit breaker.
